Glulam Navan

Glulam Beams

Glenfarne Wood Products.

Regular price €1,320.00 Sale

We can manufacture straight Glulam beams in any size. up to 12 meters in length.Wood is Scandinavian Red Deal, planed and sanded. 40 mm lamels, glued, and doweled for extra strength We can also supply treated with Protim Osmose for outside use.

Glulam beam sizes

Typically, Glulam beam sizes are represented by their width and depth. Depth of Glulam beam are range from 7 1/4 inches (184mm) to 23 7/8 inches (606mm). Width of Glulam beam are range from 3-1/8″, 3-1/2″, 5-1/8″, 5-1/2″, 6-3/4 inches and 7 inches.

Standard depths for glulam members range from 114 mm (4-1/2″) to 2128 mm (7′) or more in increments of 38 mm (1-1/2″) and l9 mm (3/4″). A member made from 38 mm (1-1/2″) laminations costs significantly less than an equivalent. Member made from l9 mm (3/4″) laminations. However, the l9 mm (3/4″) laminations allow for a greater amount of curvature than do the 38 mm (1-1/2″) laminations.

Typical depth of Glulam beam are 7 1/4 inches (184mm), 9 inches, 9 1/4 inches (235mm), 9 1/2 inches (241mm), 11 1/4 inches (286mm), 11 7/8 inches (302mm), 14 inches (356mm), 16 inches (406mm), 18 inches (457mm), 18 3/4 inches (476mm), 20 inches (508mm) and 23 7/8 inches (606mm).

Typical Glulam beam width used in residential construction include: 3-1/8, 3-1/2, 5-1/8, 5-1/2, 6-3/4 inches and 7 inches. For non-residential applications, where long spans, unusually heavy loads, or other circumstances control design, custom members are typically specified.
